Three dispersion modes are user-selectable via the front panel switch. Choose Dipole mode for side-of-listening area placement, where the two driver pair sets operate in reverse phase mode, which minimizes localization while providing broad surround sound dispersion – ideal for movie surround soundtracks. Bipole mode provides the best combination of dispersion and improved localization for pinpoint surround sound imaging with SACD, DVD-Audio, DTS® and Dolby Digital® multichannel music surround sources. A third Monopole mode allows the deactivation of one of the two driver sets, when spot-on imaging is desired, such as for discrete multichannel pop music.
For 7.1 systems such as THX Ultra2® Dolby Digital EX® and DTS ES®, the Revel S12 also features dual separated crossovers and two pairs of speaker input terminals. By removing the shorting straps on the binding post pairs, one S12can function as two distinct surround loudspeakers in a single enclosure. This unique capability allows the use of one S12 to function either as both left and right rear surrounds, or as both a side and rear surround speaker. The Concerta S12 can therefore provide a unique solution for 7.1-channel systems in tight spaces.
Thông số kỹ thuật:
|
Hãng sản xuất |
REVEL |
|
Công suất âm thanh (W) |
150 |
|
Tần số thu sóng tối thiểu (Hz) |
60Hz |
|
Tần số thu sóng tối đa (kHz) |
20kHz |
|
Trở kháng (Ω) |
8Ω |
|
Mức độ âm thanh (db) |
87dB |
