Under a program called Project Everest, JBL® engineers designed the ultimate loudspeaker system: the Project Everest DD66000. But they wanted to outdo themselves. Using the latest technologies, they created the DD67000. This three-way speaker features dual 15-inch (380-millimeter) three-layer (pure-pulp layers over and under a foam-injection core) sandwich cone woofers for articulate, authoritative bass response. Clear high and midrange frequencies come through a 4-inch (100-millimeter) pure beryllium compression driver. And a 1-inch (25-millimeter), pure-beryllium ultrahigh-frequency driver delivers sounds up to 60kHz – far above the range of human hearing.
Available in rosewood and maple, the Everest DD67000 stays true to our heritage: the world’s most coveted sound equipment.
Highlights
• Dual 15" (380mm) three-layer sandwich cone woofers for authoritative bass response
• 4" (100mm) pure-beryllium diaphragm for crystal-clear highs
• 1" (25mm), pure-beryllium diaphragm for extreme highs
• Extremely smooth and wide frequency response
• Proprietary Bi-Radial® horns
• 100 – 500 watts suggested amplifier power range
• Excellent terminals and system controls
• Bi-wiring capabilities
• Flawless enclosure construction
Thông số kĩ thuật:
| Description | Dual 15" (380mm), three-way, floorstanding speaker designed for a superlative listening experience |
| Frequency Response | 29Hz – 60kHz (half space); 45Hz – 60kHz (anechoic) |
| Recommended Amplifier Power | 500 watts |
| Sensitivity (2.83V @ 1m) | 96dB |
| Nominal Impedance | 8 ohms; 5.0 ohms @ 80Hz; 3.0 ohms @ 40kHz |
| Crossover Frequencies (Hz) | 150Hz (LF1 6dB/octave) 850Hz (LF2 24dB/octave) 20kHz (UHF 24dB/octave) |
|
Ultrahigh-frequency Drive Components |
1" (25mm) pure-beryllium compression driver |
|
High-frequency Drive Components |
4" (100mm) pure-beryllium compression driver |
|
Low-frequency Drive Components |
Dual 15" (380mm) three-layer, pure-pulp sandwich/foam core cone woofer |
| Height | 43.7” (110.9 cm) |
| Width | 38” (96.5 cm) |
| Depth | 18.5” (47 cm) |
| Weight | Weight: 313 lb (142.1 kg) / Shipping Weight: 383 lb (173.9 kg) |
| Finishes | Rosewood or Maple |
